Fortpro Air Spring Replaces 8852, 1R12-568 | F245596

Fortpro Air Spring F245596 is a high quality, exceptional performance automotive suspension component. Engineered with robust materials and enhanced features, it offers strength, durability and a multi-model compatible fit. With rigorous leak testing and proper technical specifications, this air spring provides reliability and improves vehicle suspension.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 8852, W013588852, W01-358-8852
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 10.25"
• Bead Plate Diameter Top: 9.00"
• Collapsed Height: 6.70"
• Max. Height: 23.50"
• Part Diameter: 10.12"
• Piston Height: 5.69"
• Stud Configuration-Bottom: 1
• Stud Configuration - Top: 3
• Weight:: 13.19 lbs
• Application: Peterbilt 03-07887 (Low Air Leaf)
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT64339, AB1DK23L8852
• Contitech: 91019P472
• Dayton Parts Batco: 1R121081, 1R12568, 3528852
• Firestone: 8852, W013588852, W01-358-8852
• Goodyear: 1R12568, 1R12568
• Meritor: FS8852, MAF8852
