Fortpro Air Spring Replaces 9422, 1R11-028 For Kenworth Trucks | F245588

Fortpro Air Spring F245588 works by using compressed air to absorb shocks and vibrations caused by irregularities in the road, which improves comfort, reduces driver fatigue and protects the transported load. Additionally, the Air Spring F245588 can be adjusted to accommodate different loads and riding conditions, providing a consistent level of ride height and stability.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 9422, W013589422, W01-358-9422
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 9.50"
• Bead Plate Diameter Top: 9.00"
• Collapsed Height: 3.80"
• Max. Height: 13.30"
• Part Diameter: 9.12"
• Piston Height: 2.80"
• Stud Configuration - Bottom: 2
• Stud Configuration - Top: 2
• Application: Kenworth
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT64255, AB1DK20D9422
• Contitech: 9912P314, 9912P314
• Dayton Parts Batco: 1R11028, 3529422, 3529422AG
• Firestone: 9205, 9422, 9614, 9615, W013589422, W01-358-9422
• Goodyear: 1R11028, 1R11028
• Hendrickson: S13032
• Kenworth: K30314, K30315, K3036
