Fortpro Air Spring Replaces 9466, 1R12-365 for Mack Trucks | F245582

Fortpro Air Springs F245582 for Hendrickson and Mack (Early CH Models) is a high quality type of air suspension designed for commercial vehicles that require a strong and reliable suspension. These Air Springs offer greater driving comfort, stability and safety by absorbing shock and vibration from the road and providing additional support to the vehicle's suspension system.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 9466, W01-358-9466, W013589466
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 10.00"
• Bead Plate Diameter Top: 9.00"
• Collapsed Height: 8.10"
• Max. Height: 20.00"
• Part Diameter: 10.12"
• Piston Height: 4.88"
• Stud Configuration - Bottom: 2
• Stud Configuration - Top: 2
• Application: Hendrickson, Mack (Early CH Models)
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT64276, AB1DK23K9466, AB1DK23KP442
• Contitech: 91016P410, 91016P410
• Dayton Parts Batco: 1R12365, 3529466, 49048002L
• Firestone: 9466, W013589466
• Goodyear: 1R12173, 1R12173, 1R12197, 1R12197, 1R12365, 1R12365, 1R12902
• Hendrickson: 49048000, 49048002, 490482, 49674000, 49674001, 49674002
• Mack: 364QS28, 57QL411M
