Fortpro Air Spring Replaces 9082, 1R12-092, 517559C9 | F245583

Fortpro Air Spring F245583 is a type of air suspension used in commercial vehicles. These air springs are designed with high-quality, heavy-duty materials such as synthetic rubber and steel, making them durable and reliable.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 9082, W01-358-9082, W013589082
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 10.25"
• Bead Plate Diameter Top: 9.00"
• Collapsed Height: 7.90"
• Max. Height: 20.75"
• Part Diameter: 10.12"
• Piston Height: 5.68"
• Stud Configuration - Bottom: 4
• Stud Configuration - Top: 2
• Application: Hendrickson Canada; Kelderman; Hutchens; Holland (Neway); Reyco; R & S Truck & Body; Ridewe
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT64269, AB1DK23K9082
• Contitech: 91016P310, 91016P310
• Dayton Parts Batco: 1R12092, 1R12093, 1R12509, 3529082
• Firestone: 0646, 1T15K1, 1T15M6, 646, 9082, 9084, W013589082
• Goodyear: 1R11917, 1R12092, 1R12092, 1R12093, 1R12093, 1R12134, 1R12134, 1R12509, 1R12677, 1R12677, 1R13097
• Haldex: CS112092
• Hendrickson: 365147, 9082, B2066, S4041
