Fortpro Air Spring Replaces 9069, 1R12-069 For Peterbilt Trucks | F245587

Fortpro Air Spring F245587 offers a combination of durability, comfort, safety and cargo protection that makes it a reliable and efficient option for commercial vehicles. Their superior performance and benefits in terms of productivity and maintenance make them a popular choice in the transportation industry.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring / Cab Air Bag
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 9069, W013589069, W01-358-9069
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 9.50"
• Bead Plate Diameter Top: 9.00"
• Collapsed Height: 7.50"
• Max. Height: 18.00"
• Part Diameter: 10.12"
• Piston Height: 4.75"
• Stud Configuration - Bottom: 1
• Stud Configuration - Top: 3
• Application: Peterbilt
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT64274, 566ER9069, AB1DK23I9069, AB1DK23IA312
• Contitech: 91014P312, 91014P312
• Dayton Parts Batco: 1R12069, 1R12669, 1R12676, 3529069
• Firestone: 9069, W013589069, W01-358-9069
• Goodyear: 1R12069, 1R12069, 1R12669, 1R12669
• Hendrickson: 9069, S13031
• Meritor: FS9069, MAF9069
