Fortpro Air Spring Replaces 8829, 1R12-615 | F245597

Fortpro Air Spring F245597 is a high quality air suspension option for heavy duty vehicles. With its level of carry and load protection, smooth ride and superior durability, this air spring ensures optimal performance, driver comfort and safety in the most demanding applications.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 8829, W013588829, W01-358-8829
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 10.00"
• Bead Plate Diameter Top: 9.00"
• Collapsed Height: 5.90"
• Max. Height: 21.65"
• Part Diameter: 10.12"
• Piston Height: 4.65"
• Stud Configuration-Bottom: 1
• Stud Configuration - Top: 2
• Weight:: 11.90 lbs
• Application: Compatible with Volvo 3934699, 8079902
• VMRS: 016-008-000

CrossReference:

• Automann: AB1DF23HP1154, AB1DK23P8829
• Contitech: 91016P449
• Dayton Parts Batco: 1R121083, 1R12615, 3528829
• Firestone: 8829, W013588829, W01-358-8829
• Goodyear: 1R12405, 1R12405, 1R12536, 1R12595, 1R12615, 1R12615, 1S12002, 1S12002, 1S12033, 1S12035, 566241010
• Meritor: FS8829, MAF8829
